UNI-T UPO1054 Digital Oscilloscope- 50 Mhz 4 Channel

The UNI-T UPO1054 digital oscilloscope incorporates the innovative Fast Acquire Phosphor technology, developed by UNI-T, to deliver exceptional performance. Key features include:

• Bandwidth: Available in three options—50 MHz, 100 MHz, and 200 MHz.
• Sampling Rate: Real-time sampling rate of 2 GSa/s.
• Channels: Equipped with four channels as standard for diverse measurement capabilities.
• Waveform Capture Rate: 150,000 waveforms per second, with an enhanced Fast Acquire mode offering 500,000 waveforms per second.
• Storage Depth: Up to 56 Mpts for detailed waveform storage.
• Vertical Range: 8-bit vertical resolution, with a vertical scale range of 500 μV/div to 20 V/div at 1 MΩ.
• Gain Accuracy: For signals <10 mV, the accuracy is ±4.0% full scale, and for signals ≥10 mV, the accuracy is ±3.0% full scale.
• Time Base Range: Adjustable from 2 ns/div to 1000 s/div for flexibility in time-domain analysis.
• Frequency Meter: 7-digit frequency meter for precise frequency measurements.
• Bus Analysis: Supports RS232/UART, I2C, and SPI protocols for in-depth bus analysis.
• Auto Measurement: Offers 36 automated measurements for fast and accurate results.
• Waveform Recording: Capable of recording up to 120,000 waveforms for further analysis.
• FFT Points: 1 Mpts FFT for signal analysis in the frequency domain.
• Interfaces: Includes USB Host, USB Device, and LAN interfaces for convenient connectivity.
• Display: 7-inch TFT-LCD screen with a resolution of 800x480 for clear waveform visualization.

Additionally, the oscilloscope comes with a 3-year warranty and is widely used in fields such as communications, semiconductor testing, computer systems, industrial electronics, automotive applications, research, development, and education.
